Fire rated DCC 600
DAMPA® DCC 600 System is a B-15 fire rated, suspended Marine Ceiling System consisting of linear ceiling panels.
Fast and efficient installation is assured, as ceiling panels are supplied ‘pre-cut’ in accordance with customer drawings and specifications.
By use of only a few basic components a functional and aesthetically pleasing ceiling can be designed to suit all types of areas.
DAMPA® DCC 600 Ceiling Panels are made from pre-painted 0.6 mm galvanised steel.
The panels can be supplied perforated or plain, and in any specified length, from 600 to 3000 mm as standard. Lengths under 600 mm down to 150 mm can be specified on request.
All panels are 26 mm deep and are supplied with end closings as standard.
DAMPA® DCC 600 has been tested in accordance with the lastest IMO and SOLAS requirements regarding resistance to fire, flame spread and toxicity.
The DCC 600 Ceiling Panels are stove- enamelled with non-toxic polyester paint prior to forming, resulting in a superior finish and excellent durability.
Colours and surfaces
The panels are available in DAMPA® Pure White (RAL 9010) as standard, and almost any other colour are available on request.
DCC 600 Panels are available in brushed stainless steel; quality AISI 304, grain size 220, which is specially suitable for use in galleys, laundries, etc.
Further, almost any colour shade is available on request in the following gloss levels (at 60˚), designated by code numbers 1, 2 or 5:
xxx-1, gloss 80 +/- 5
xxx-2, matt 10 +/- 3
xxx-5, anti-reflection/textura 0-7 (developed by DAMPA for e.g. wheelhouse ceilings).
Special colour requests will be converted to the nearest NCS (Natural Colour System) colour code.
